Menu-COMM.05: COM1 Output Format
Function COM1 Output Format
Display Part Meaning
CFM1. 0
22 byte of CAS
CFM1. 1 10 byte of CAS
Set Range
(0 ~ 2)
CFM1. 2 18 byte Format(AND, FINE)
Note 1. Refer to <Appendix 1> for the communication format
Menu-COMM.07: COM1 Communication Method
Function COM1 Communication Method (RS-232 - Output mode)
Display Part Meaning
CMD1. 0
Data is not transmitted
CMD1. 1 Transmitted only if the print key is pushed
CMD1. 2
Transmitted in both stable/unstable cases
(Stream Mode)
CMD1. 3 Transmitted only if the weight is stable
CMD1. 4 Command Type 1
CMD1. 5 Command Type 3
Set Range
(0 ~ 6)
CMD1. 6 Modbus protocol
Note 1. Refer to Appendix 2, 3 for command types.
Menu-COMM.07: Set COM2 Port
Function Com2 Port Setting (Parity Bit – RS485)
Display Part Meaning
CPR2. 0
Data Bit 8, Stop Bit 1, Parity Bit : None
CPR2. 1 Data Bit 7, Stop Bit 1, Parity Bit: Even
CPR2. 2 Data Bit 7, Stop Bit 1, Parity Bit: Odd
CPR2. 3 Data Bit 7, Stop Bit 2, Parity Bit: Odd
CPR2. 4 Data Bit 8, Stop Bit 1, Parity Bit: Even
Set Range
( 0~ 5)
CPR2. 5 Data Bit 8, Stop Bit 1, Parity Bit: Odd
