31
2. Communication Setting
Menu-COMM.01: Equipment Number
Function Equipment Number
Display Part Meaning
Set Range
(0 ~ 99)
D-ID. XX
Initial Value : 0
Desired device ID may be entered.
Note 1. This function can be used as the indicator unique ID when using COMMAND mode.
Menu-COMM.02: Set COM1 Port
Function Com1 Port Setting (Parity-RS232)
Display Part Meaning
CPR1. 0
Data Bit 8, Stop Bit 1, Parity Bit : None
CPR1. 1 Data Bit 7, Stop Bit 1, Parity Bit: Even
CPR1. 2 Data Bit 7, Stop Bit 1, Parity Bit: Odd
CPR1. 3 Data Bit 7, Stop Bit 2, Parity Bit: Odd
CPR1. 4 Data Bit 8, Stop Bit 1, Parity Bit: Even
Set Range
( 0~ 5)
CPR1. 5 Data Bit 8, Stop Bit 1, Parity Bit: Odd
Menu-COMM.03: Set COM1 RS-232C Baud Rate
Function COM1 Baud Rate Setting
Display Part Meaning
CBR1. 0 1,200 bps
CBR1. 1 2,400 bps
CBR1. 2 4,800 bps
CBR1. 3
9,600 bps
CBR1. 4 19,200 bps
CBR1. 5 38,400 bps
CBR1. 6 57,600 bps
Set Range
(0 ~ 7)
CBR1. 7 115,200 bps
Menu-COMM.04: Set COM1 Out Data
Function COM1 Out Data Setting
Display Part Meaning
CWT1. 0
Displayed value is transmitted
CWT1. 1 Gross Weight is transmitted
Set Range
(0 ~ 2)
CWT1. 2 Net weight is transmitted
To Next Page
