2. Communication Setting
Menu-COMM.01: Equipment Number
Function
Equipment Number
Set Range
(0 ~ 99)
Display Part
Meaning
D-ID. XX
Initial Value : 0
Desired device ID may be entered.
Note 1. This function can be used as the indicator unique ID when using COMMAND mode.
Menu-COMM.02: Set RS232 Port
Function
RS232 Port Setting (Parity-RS232)
Set Range
( 0 ~ 5)
Display Part
Meaning
CPR1. 0
Data Bit 8, Stop Bit 1, Parity Bit : None
CPR1. 1
Data Bit 7, Stop Bit 1, Parity Bit: Even
CPR1. 2
Data Bit 7, Stop Bit 1, Parity Bit: Odd
CPR1. 3
Data Bit 7, Stop Bit 2, Parity Bit: Odd
CPR1. 4
Data Bit 8, Stop Bit 1, Parity Bit: Even
CPR1. 5
Data Bit 8, Stop Bit 1, Parity Bit: Odd
Menu-COMM.03: Set RS-232C Baud Rate
Function
RS232 Baud Rate Setting
Set Range
(0 ~ 7)
Display Part
Meaning
CBR1. 0
1,200 bps
CBR1. 1
2,400 bps
CBR1. 2
4,800 bps
CBR1. 3
9,600 bps
CBR1. 4
19,200 bps
CBR1. 5
38,400 bps
CBR1. 6
57,600 bps
CBR1. 7
115,200 bps
Menu-COMM.04: Set RS232 Out Data
Function
RS232 Out Data Setting
Set Range
(0 ~ 2)
Display Part
Meaning
CWT1. 0
Displayed value is transmitted
CWT1. 1
Gross Weight is transmitted
CWT1. 2
Net weight is transmitted
