8 | Page
Figure
1: TFO-5
RECEIVING
ORIENTATION IMAGES
Exhaust Port with Sliding Dampener
Main Temperature and High Limit Sensor Probes
Door Latch
Control Panel
Chamber Gasket
Access Port
Oven Chamber
