4-OPERATINGINSTRUCTIONS
4.Afterswitch(1)hasbeenoperated,thesetowand-
pressurewillbedisplayedforasetamountoftime.
1B507B50Z26
NOTE:Topreventfailureordamagetothetool,make
surethatyouselectthecorrectcircuitcongurationand
owrateandpressureforthetool.
26D72C3127
5.Proportionalswitch
(1)=Proportionalswitch(Optioncontrolswitch).
(2)=Optioncontrolswitch
(3)=Hornswitch
(4)=Proportionalswitch(Optioncontrolswitch)
(5)=Optioncontrolswitch
(6)=Engineidleswitch
3207DF3828
4-36
