Case CX300C - Auxiliary hydraulic circuit flow patterns; Option pressure setting

4-OPERATINGINSTRUCTIONS
6.Usetheproportionalswitchtooperatetheconcrete
crusher.
NOTICE:InBucketmode,donotcarryoutoperationus-
ingauxiliaryline.Ifyoudothatthewarningmessage
“Auxiliaryset-uprequired”willbedisplayedwithintermit-
tentwhistlesound.Stopoperationimmediatelyandcarry
outauxiliaryset-up.
NOTE:Topreventfailureordamagetothetool,make
surethatyouselectthecorrectcircuitcongurationand
owrateandpressureforthetool.
EC3339BB29
Auxiliaryhydrauliccircuitowpatterns
Flowpatternscanbeselectedfromthe20shownbelow.
NOTE:Thenumberofsettingpatternsis10maximum.
1ow2ows
243l/min(53.5UKgpm)486l/min(106.9UKgpm)
225l/min(49.5UKgpm)468l/min(102.9UKgpm)
209l/min(46.0UKgpm)452l/min(99.4UKgpm)
189l/min(41.6UKgpm)432l/min(95.0UKgpm)
165l/min(36.3UKgpm)408l/min(89.7UKgpm)
144l/min(31.7UKgpm)387l/min(85.1UKgpm)
122l/min(26.8UKgpm)365l/min(80.3UKgpm)
101l/min(22.2UKgpm)344l/min(75.7UKgpm)
76l/min(16.7UKgpm)319l/min(70.2UKgpm)
50l/min(11.0UKgpm)293l/min(64.5UKgpm)
Optionpressuresetting
Anoptionpressurefrom160-40MPa(23208.0-5802.0
psi)canbeselectedin0.5MPa(72.5psi)increments.
