Casella CEL-35X dBadge Users Handbook – Page 21
5.5 Reviewing Measurement Run Data
As soon as a measurement run has been stopped, the dBadge will
automatically display results from the completed measurement run.
The display will automatically cycle as shown in Figure 21. The
screen contents will depend upon which display mode is selected
(ISO or OSHA).
The last screen, highlighted in red, is only available on the CEL-
352 dBadge ‘Plus’ model
Figure 21
ISO View
OSHA View
Instantaneous
SPL and time
Battery and
memory
status
Duration of last
measurement
run
Time averaged
and peak data
Calculated
noise
exposure data
DURATION
07:45:12
LAEQ 89.9
LCPK
101.4
DURATION
07:59:32
LAVG
111.4
LZPK
119.4
,dB
OSHA DOSE
4.3 %
PA Hrs
3.20
10
Hrs
80
Hrs
10
Hrs
80
Hrs
LAS 109.1
14:05:09
dB
LAF 112.3
13:45:03
dB
LCEQ 94.7
dB
LC-A 4.8
dB
LCEQ 94.7
dB
LC-A 4.8
dB
Hearing
protection
selection data
Projected noise
exposure data
PROJ DOSE
352.5%
PROJ DOSE
175.3 %
PROJ DOSE
352.5 %
