Casella CEL-35X dBadge Users Handbook – Page 23
On the language screen, the available options are English,
Spanish, French, Italian, German and Portuguese.
For further details about the ‘Display Mode’ see section 5.7.
The ‘Alarms’ can be switched either ‘on or ‘off’ using this menu, but
the alarm levels are set using the dB35 software. For further
details of the ‘Alarms’ see section 5.8.
When on the clear memory screen, the memory can be cleared by
first pressing the ‘L’
key to change the ‘No’ option on the screen
to ‘Yes’. Then press the ‘R’
key to confirm. A second screen will
appear requesting confirmation that you wish to delete the
memory. Use the ‘L’ key to change the option to ‘Yes’ and if you
wish to delete the memory press ‘R’
to confirm.
Once all the options within the configuration menu have been set,
the display will return to the standard screens as described in
section 5.
5.7 Display Mode
The selected display mode specifies which key results are
displayed on the screen upon completion of a measurement run.
Regardless of which display mode is set, the dBadge measures
ALL parameters during every measurement run. Once downloaded
to the dB35 software, all measured data can be viewed. The key
displayed results set can be either configured to ISO (for Europe)
or OSHA (for U.S.A), as shown in the table below.
DATA ISO OSHA
Instantaneous SPL
L
AF
L
AS
Time Averaged Parameter
L
Aeq
, L
Ceq
* L
Aavg
, L
Ceq
*
Peak Value
L
Cpeak
L
Zpeak
Dose Value Pa
2
Hours,
Projected %
Dose
% Dose,
Projected %
Dose
* CEL-352 dBadge ‘Plus’ model only
