Casio CDP-200R User Manual

Controlling the Keyboard Sounds
E-12
You can use the following procedure to layer two different
tones (such as piano and strings) so they sound
simultaneously when you press a keyboard key.
1. Select the first tone you want to use.
Press
bt
and then use
cl
(10-key) to select the tone you
want.
Example: 026 ELEC.PIANO 1
2. Press
ct
.
3. Use
cl
(10-key) to select the second tone you
want.
Example: 212 STRINGS
4. Play something on the keyboard.
Both tones sound at the same time.
5. Pressing
ct
again to unlayer the keyboard (so it
plays only the tone you selected in step 1).
• Each press of
ct
toggles between layered (two tones)
and unlayered (one tone).
You can use the procedure below to assign different tones to
the right range and left range of the keyboard, so it sounds
like you are playing an ensemble between two instruments.
1. Select the tone for the right side range (page
E-11).
Press
bt
and then use
cl
(10-key) to select the tone you
want.
Example: 335 FLUTE 1
2. Press
cs
.
3. Use
cl
(10-key) to select the left side range tone
you want.
Example: 056 VIBRAPHONE 1
4. Play something on the keyboard.
This will sound the tones assigned to the left and right
side ranges of the keyboard.
Layering Two Tones
E . P i a n o 1
Lights
St r in
g
s
Disappears
Splitting the Keyboard between
Two Different Tones
To select the two tones for a split keyboard
Flute 1
Lights
V i b e s 1
Split point
F3
VIBRAPHONE 1 FLUTE 1
CDP200R_e.book 12 ページ ２００８年４月２１日 月曜日 午後３時４分

Casio CDP-200R Specifications

General

MIDI-keyboard number of keys	88 keys
Product color	Black
Pitch bend wheel	Yes
Interface	USB
Dimensions (WxDxH)	1333 x 278 x 133 mm
Power consumption (typical)	18 W

Weight and Dimensions

Weight	12000 g
