33
(4) Bluetooth connection status LED
This is used for notification of Bluetooth connection status.
Item Specification Attribute
Connection established
via SS wireless
On in blue for 1 second, off for 2 seconds L_BT
Time continuously ON
- Use as the scanner scanning LED has priority. User access from a private library is also possible.
(5) User-defined LED
This is used for other notifications defined by the user.
Item Specification Attribute
User definition Color: Refer to “2.1 List of Functions”.
Time: Set on time and off time
Time continuously ON 30 minutes (off when VDET is detected.)
- Use as the scanner scanning LED has priority. User access from a private library is also possible.
(6) W-WAN connection status LED
This is used for notification of W-WAN connection status.
Item Specification Attribute
Connection established
via W-WAN
On in orange for 1 second, off for 2 seconds L_WWAN
- Use as the scanner scanning LED has priority. User access from a private library is also possible.
- W-LAN wireless, W-WAN, and GPS all control the LED in the same color category, so the have the
same lighting specification.
(7) GPS connection status LED
This is used for notification of GPS connection status.
Item Specification Attribute
Connection established
via GPS
On in orange for 1 second, off for 2 seconds L_GPS
- Use as the scanner scanning LED has priority. User access from a private library is also possible.
- W-LAN wireless, W-WAN, and GPS all control the LED in the same color category, so the have the
same lighting specification.
