Casio SE-S100 Service Manual

SE-S100 / PCR-T285 / PCR-T295
CONTENTS
1. SPECIFICATIONS .......................................................................................................... 1
2. INITIALIZATION .............................................................................................................2
3. DISASSEMBLY ............................................................................................................... 9
4. DIAGNOSTIC OPERATION .......................................................................................... 21
5. TECHNICAL INFORMATION ........................................................................................ 32
6. EXPLODED VIEW / PARTS LIST ................................................................................. 34
*
Caution ! / Attention !
Battery
• Risk of explosion if battery is replaced by an incorrect type.
• Dispose of used batteries according to the instructions.
Batterie
• il y a danger d’explosion si la batterie est remplacée par une batterie de type incorrect.
• Mettez les batteries hors d’usage au rebut en respectant les instructions.

Casio SE-S100 Specifications

General

Types of payment	Cash
Number of clerks/departments	24
Number of Price Look-Up codes (PLUs)	2000 PLUs
Power source	AC
AC input voltage	100-240 V
Supported paper width	58 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Backlight	Yes
Display digits	10 digits
Second display type	LCD
Display number of lines	2 lines
Display number of characters	20

Weight and Dimensions

Depth	345 mm
Width	326 mm
Height	167 mm
Weight	3300 g
