Casio SE-S100 Service Manual

SE-S100 / PCR-T285 / PCR-T295
– 34 –
7. EXPLODED VIEW / PARTS LIST
MODEL : SE-S100 / PCR-T285 / PCR-T295
(EX-286)
<CONTENTS>
6-1. Exploded View ................................................................................................... 35
6-2. Parts List ............................................................................................................ 37
6-3. Drawer S-type (DL-1335A / DL-1844A) ............................................................. 43
6-4. Drawer M-type (DL-2816A) ............................................................................... 45
NOTES :
1. Price and specifi cations are subject to change without prior notice.
2. As for spare parts order and supply, refer to the “GUIDEBOOK for Spare Parts Supply”, published
separately.
3. The numbers in item column correspond to the same numbers in drawing.
4. CASIO does not supply the spare parts without parts code.
5. Refer to the latest “Parts Price Code” at “PARTS FINDER” on the Casio Service WEB site
(https://www.servicecasio.com).
6. Remarks
Q’ty: Quantity used per unit
R: Rank A = Essential
B = Stock recommended
C = Less recommended
X = No stock recommended

Casio SE-S100 Specifications

General

Types of payment	Cash
Number of clerks/departments	24
Number of Price Look-Up codes (PLUs)	2000 PLUs
Power source	AC
AC input voltage	100-240 V
Supported paper width	58 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Backlight	Yes
Display digits	10 digits
Second display type	LCD
Display number of lines	2 lines
Display number of characters	20

Weight and Dimensions

Depth	345 mm
Width	326 mm
Height	167 mm
Weight	3300 g
