Casio SE-S100 Service Manual

SE-S100 / PCR-T285 / PCR-T295
– 36 –
DISPLAY
PCB ASSY/E286-1
FUSE
FU1
26
22
23
27
20
44
40
28
30
31
33
37
38
43
41
42
50
49
47
17 19
51
48
46
21
24
S3
45 ×5
S6 ×2
29
S7 ×3
S5 ×3
S3 ×5
S3
S3
S5
25
M-type only
34-1
38-1
34-2
36
32
34
KEY-BOARD-ASSY
S3 ×2 S8 ×2
PS-ASSY
S3
S10
39
S5
M-type only
S7
S-type
M-type
S4
S9
MAIN-UNIT
16
18
M-type S-type
Rear Display
Display Board
35

Casio SE-S100 Specifications

General

Types of payment	Cash
Number of clerks/departments	24
Number of Price Look-Up codes (PLUs)	2000 PLUs
Power source	AC
AC input voltage	100-240 V
Supported paper width	58 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Backlight	Yes
Display digits	10 digits
Second display type	LCD
Display number of lines	2 lines
Display number of characters	20

Weight and Dimensions

Depth	345 mm
Width	326 mm
Height	167 mm
Weight	3300 g
