Casio SE-S100 Service Manual

SE-S100 / PCR-T285 / PCR-T295
– 38 –
S-type Drawer
1: SE-S100SB_BK
2: SE-S100SB_GD
3: SE-S100SB_RD
4: SE-S100SB_SR
5: SE-S100SC_GD
6: SE-S100SC_RD
7: SE-S100SC_SR
8: SE-S100SG_BK
9: SE-S100SG_GD
10: SE-S100SG_RD
11: SE-S100SG_SR
12: SE-S100SK_BK
13: SE-S100SK_GD
14: SE-S100SK_RD
15: SE-S100SK_SR
16: PCR-T285_BK
17: PCR-T295_BK
1234567891011121314151617
RN Item Code No. Parts Name Specification
Q'T
Y
U-CASE-ASSY
N 16 10508645 CASE ASSY/UPPER TK-RJE504496*006 1 1 1 C
N 16 10508644 CASE ASSY/UPPER TK-RJE504496*005 1 1 1 1 C
N 16 10508643 CASE ASSY/UPPER TK-RJE504496*004 1 1 1 1 C
N 16 10508642 CASE ASSY/UPPER TK-RJE504496*003 1 1 1 1 C
N 16 10508641 CASE ASSY/UPPER TK-RJE504496*002 1C
N 16 10508640 CASE ASSY/UPPER TK-RJE504496*001 1C
17 10294939 SPRING/BATTERY/B-2E RJE502620-001V01 1 1111111111111111C
18 63452238 SPRING/BATTERY/G55 A42606B-1 1 1111111111111111C
19 10294940 SPRING/BATTERY/G67E RJE502622-001V01 1 1111111111111111C
20 10350060 CABLE/SUBASSY/BATTERY RJE503227*001V02 1 1111111111111111C
21 10445426 ROLLER/D-P RJE504041-001V01 2 2222222222222222C
22 10236317 CUTTER/PAPER E441364-001V02 1 1111111111111111C
23 10503749 SHEET/BATTERY RJE504492-001V01 1 1111111111111111X
24 10445805 PLATEN ARM RJE504004-001V01 1 1111111111111111C
25 10451728 MOTOR TK-E441295*003 1 1111111111111111A
26 10334571 MODE KEY TK-E341249*004V01 1 1111111111111111C
27 10501928 PRINTER FTP628MCL518#70-R 1 1111111111111111A
28 10262839 STOPPER RJE502189-001V01 1 1111111111111111X
29 10500432 MOUNT/PRINTER RJE504378-001V01 1 1111111111111111C
30 10500433 MOUNT/PCB RJE504379-001V01 1 1111111111111111C
31 10497745 HOLDER/IC RJE504404-001V01 1 1111111111111111C
32 10500423 CABLE/FFC/JOINER E441341-020V04 1 1111111111111111C
33 10507407 PCB ASSY/E286-1 TK-RJE504414*001V01 1 1111111111111111A
FU1 10225980 FUSE (600mA) 230.600MXP 1 1111111111111111A
S3 Screw (3x8) S-BDPT-3X8Z3 1010101010101010101010101010101010 X
S4 Screw (3x8) S-BDST-3X8Z3 11111111111111111X
S5 Screw (3x6, washer) S-PASEMA-3X6Z3 4 4444444444444444X
S6 Screw (2x5) S-BDST-2X5Z3 22222222222222222X
S7 Screw (3x5) S-BDST-3X5ZC 33333333333333333X
S8 Screw (3x14) S-BDPT-3X14Z3 22222222222222222X

Casio SE-S100 Specifications

General

Types of payment	Cash
Number of clerks/departments	24
Number of Price Look-Up codes (PLUs)	2000 PLUs
Power source	AC
AC input voltage	100-240 V
Supported paper width	58 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Backlight	Yes
Display digits	10 digits
Second display type	LCD
Display number of lines	2 lines
Display number of characters	20

Weight and Dimensions

Depth	345 mm
Width	326 mm
Height	167 mm
Weight	3300 g
