Casio SE-S100 Service Manual

SE-S100 / PCR-T285 / PCR-T295
– 44 –
Parts List
1: DL-1335A
2: DL-1844A
12
1 10449184 CASE/MAIN/BK RJE504018-001V01 1 1 B
2 10449185 LEVER/HOOK RJE504008-001V01 1 1 C
3 10384548 ROLLER/PLASTIC PB-19B2 4 4 B
4 10201068 LOCK/SPRING RJE500007-001V02 1 1 C
5 10194207 SPRING/PRESS E412137-001V02 1 1 C
6 10167366 RUBBER/PAD RJE501204-001V01 1 1 C
7 10080189 SUB ASSY/SOLENOID E341255*2 1 1 B
8 10260417 AXIS/LEVER HOOK RJE502184-001V01 1 1 C
9 10267909 SPRING/PLUNGER RJE502245-001V01 1 1 C
10 10449179 CASE/BILL COIN RJE504011-001V01 1 X
10 10449176 CASE/BILL COIN RJE504011-002V01 1 X
11 10231347 SUB ASSY/BILL HOLDER RJE501337*001V03 1 X
12 10194229 PLATE/BILL HOLDER E341289-001V02 1 X
13 10230104 BILL HOLDER SUB ASSY E341290*002V04 3 C
14 10276626 SPRING/BILL HOLDER E441357-001V03 4 3 X
15 10298553 PLATE/PARTITION RJE500214-002V03 2 C
16 10298558 CASE/COIN RJE500212-002V04 1 1 C
17 10298552 SEPARATER/COIN RJE500213-002V03 4 4 C
18 10500424 LOCK/CYRINDER RJE502350*003V01 1 1 C
19 54400287 RIVETS/COLD HEADED 5X26 1 1 X
20 55801452 CS FIX CSTW-5 1 1 X
21 10503758 RUBBER/PAD RJE501204-002V01 4 4 C
W1 Washer 11.5X6.5XT0.8 2 2 X
S1 Screw (3x8) S-PAPT-3X8Z3 5 5 X
S2 Screw (3x5) S-PAST-3X5NI 3 X
S3 Screw (4x25) S-WBPT-4x25Z3 1 1 X
RSpecificationN Item Code No. Parts Name
Q'TY

Casio SE-S100 Specifications

General

Types of payment	Cash
Number of clerks/departments	24
Number of Price Look-Up codes (PLUs)	2000 PLUs
Power source	AC
AC input voltage	100-240 V
Supported paper width	58 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Backlight	Yes
Display digits	10 digits
Second display type	LCD
Display number of lines	2 lines
Display number of characters	20

Weight and Dimensions

Depth	345 mm
Width	326 mm
Height	167 mm
Weight	3300 g
