Casio SE-S100 - Page 48

SE-S100 / PCR-T285 / PCR-T295
– 46 –
Parts List
DL-2816A
N Item Code No. Parts Name Specification Q'TY R
1 10445372 CASE/MAIN RJE502983-002V02 1 B
2 55000619 ROLLER/DELRIN DR-19B1 2 B
3 10236805 LEVER/HOOK E341286-001V03 1 C
4 10127603 AXIS/LEVER HOOK RJE500674-001V01 1 C
5 10201068 LOCK/SPRING RJE500007-001V02 1 C
6 62465010 SPRING/PRESS E412069-1 1 X
7 10078759
RAIL/MLED18
E240841-1 1 C
8 10078760
RAIL/MRED18
E240842-1 1 C
9 10194208 RUBBER/DUMPER RJE500005-001V02 4 X
N 10 10503758 RUBBER/PAD RJE501204-002V01 4 C
11 10080191 SOLENOIDO SUB ASSY E341301*4 1 B
12 10203849 DRAWER SUB ASSY E341274*001V03 1 C
13 52000106 RIVET 5X30 1 X
N 14 10500424 LOCK/CYLINDER RJE502350*003V01 1 C
15 10324878 PANEL/FRONT RJE502991-001V01 1 C
16 10490568 BILL COIN CASE ASSY TK-RJE501368*10 1 C
17 10230104 BILL HOLDER SUB ASSY E341290*002V04 4 C
18 10276626 SPRING/BILL HOLDER E441357-001V03 4 A
19 10194233 PLATE/BILL HOLDER E240845-001V02 1 X
20 10445634 CASE/BILL RJE504023-001V01 1 X
21 10298559 CASE/COIN RJE500217-002V02 1 C
22 10298554 SEPARATER/COIN RJE500216-002V02 6 B
23 10445635 SEPARATER/BILL RJE504024-001V01 3 B
N 24 10378459 ROLLER/DELRIN PB-19B1 2 B
N1 6-NUT N-HXT1-6Z3 2 X
N2 6-NUT N-HXT1-4Z3 1 X
W1 Washer W-6X13-1.0Z3 2 X
W2 Washer 6X13X1.0 ZMC-3 2 X
S1 Screw (4x10) S-WSPT-4X10Z3 6 X
S2 Screw (4x25) S-PADLMA-4X25Z3 1 X
S3 Screw (3x10) 3X10 NI 4 X
S4 Screw (3x8) 3X8 ZMC-3,, 3 X
S5 Screw (3x5) 3X5 NI... 4 X
S6 Screw (3x8) S-BDPT-3x8Z3 3 X
