54 Specifications
Supported timing for HDBaseT input
• PC timings
• Video timings
Resolution Mode
Vertical Frequency
(Hz)
Horizontal
Frequency (kHz)
Pixel Frequency
(MHz)
640 x 480 VGA_60 59.940 31.469 25.175
800 x 600 SVGA_60 60.317 37.879 40.000
1024 x 768 XGA_60 60.004 48.363 65.000
1280 x 720 1280 x 720_60 60 45.000 74.250
1280 x 768 1280 x 768_60 59.870 47.776 79.5
1280 x 800 WXGA_60 59.810 49.702 83.500
1280 x 1024 SXGA_60 60.020 63.981 108.000
1280 x 960 1280 x 960_60 60.000 60.000 108
1400 x 1050 SXGA+_60 59.978 65.317 121.750
1920 x 1200@60Hz
1920 x 1200_60 (Reduce
Blanking)
59.95 74.038 154
1920 x 1080 (VESA) 1920 x 1080_60 59.963 67.158 173
The timings showing above may not be supported due to EDID file and VGA graphic card limitations. It is
possible that some timings cannot be chosen.
Cable type Cable Range
Pixel
Frequency
Supported HDMI format
CAT 5e/CAT 6a 100m <=225MHz
720x480p/60Hz 4:3 24bit 30bit 36 bit
1280x720p/60Hz 16:9 24bit 30bit 36 bit
1920x1080i/60Hz 16:9 24bit 30bit 36 bit
1920x1080p/60Hz 16:9 24bit 30bit 36 bit
720x576p/50Hz 4:3 24bit 30bit 36 bit
1280x720p/50Hz 16:9 24bit 30bit 36 bit
1920x1080i/50Hz 16:9 24bit 30bit 36 bit
1920x1080p/50Hz 16:9 24bit 30bit 36 bit
CAT 5e 70m >225MHz 3840 x 2160 60Hz YUV 4:2:0 24bit
CAT 5e 70m >225MHz 3840 x 2160 30Hz 24bit
CAT 6a 100m >225MHz 3840 x 2160 30Hz 24bit
