230 Series Auger Packer
74 OF 115
Timer Explanation
Feed Gate
This timer is used to hold the feed gate closed at the end of a bagging cycle to allow
the chamber on an air packer to allow the extra pressure through the exhaust on the
three way valve. It is adjusted in 0.1 second increments. Factory Setting is 1.5 seconds.
Bag Chair
This timer is the total length of time the chair solenoid is on. This should be set long
enough for the chair to achieve the full stroke of the cylinder. It is adjusted in 0.1
second increments. Factory Setting is 2.0 seconds.
Tube Clean Out
Is the blast of high pressure air at the end of a cycle used to remove all the product
from the filling tube into the bag after the fill is over. It is adjusted in 0.1 second
increments. Factory Setting is 1.0 seconds.
Reverse For 200 Model Packers only
Is the time the auger is in reverse at the end of the cycle. It is adjusted in 0.1 second
increments. Factory Setting is 0.5 seconds.
Adjusting the Timers
To adjust the timers you first scroll to the screen of the timer you want to adjust using
the A or B key. At that screen there will be flashing blocks over the time. Press the
green OK key and the numbers should now be flashing. While the numbers are
flashing you can us the + key to add time in 0.1 second increments of the – key to
subtract time in 0.1 second increments. When you get to the time you desire press the
Green OK key again and the numbers should have blocks flashing over them again.
When the machine is started the PLC will revert back to the Choice Bagging screen.
