WASTE WATER TANK
To connect to the waste water tank probe.
FRESH WATER TANK
To connect to the water tank probe.fresh
CONTROL PANEL
To connect to the 16 poles connector of the control panel.
SIGNALS ” (OPTION “A )
1) + input signal contact key engine starting.
2) + input signal “S” net coming from the CBE battery charger
MASSES
To connect to the mains' masses.
CAR BATTERY
To connect to the positive pole of the car battery.
MASSES
To connect to the negative pole of the services battery or to the chassis of the
vehicle.
SERVICES BATTERY
To connect to the positive pole of the services battery.
1 2
22
16
17
1 A8
19
20
13
FUSE
5
3
1
4
2
FUSE
6
9
7
8
2) + output water pump - toilet, it depends on the pump switch.
3) + output awning light, it depends on the awning switch.
4-5-6) + output lights group A”“ ,
(PC200) or on the main general button (PC100).
it depends on the lights switch
7-8-9) + output lights group B”“ ,
(PC200) or on the main general button (PC100).
it depends on the lights switch
1) + output heating it depends on the lights switch , (PC200) or
on the main general button (PC100).
1) + output aux (solar regulator), direct B2.
2-3) + output 3 way function / AES refrigerator“ ”
5-6) + output gas mains’ supply (fridge, kitchen, boiler valve).
4) + output electric step (direct B2).
MAINS
MAINS
1
4 7
2
5 8
3
6
9
1
4
2
5
3
6
14
15
SIGNALS (OPTION ”)“B
2) + input signal contact key engine starting.
1) - input “D+” negative signal (-)
2) /
1) + input signal “S” net coming from the CBE battery charger.
1
2
1
2
18B
