11. Technical specifications
Display
3.5” TFT LCD 480 x 320 Touch Screen | 600 nits | Supports PIN on Glass | front-glass
hardness 6 Mohs
Card Readers
Contactless
Scanner
Reads 1D & 2D codes
Memory
512 MB Flash + 512 MB DDR RAM
Keys / buttons
1 x Reset key (rear)
Audio
1 Speaker (side)
Dimensions
CCV Edge IM15
108,4 x 75 x 43mm (W x H x D), 108,4 x 75 x 18,5mm (W x H x D) outside the
machine, 72 x 60 x 24,5mm (W x H x D) within the machine (without cables and
mounting accessories)
CCV Frame IM15
141 x 92 x 49mm (W x H x D), 141 x 92 x 46mm (W x H x D) within the machine
(without cables and mounting accessories)
Front Frame cut-out
CCV Edge IM15
73 x 61mm, EVA EPS CDM compliant
CCV Frame IM15
CCV cut-out compatible with OPP-C60c product
Connectivity
1 x USB Host (USB-A) | 1 x USB Device (USB-C) | 1 x LAN | 1 x RS232 | 1 x MDB
WiFi 5 GHz | Bluetooth 5.0
4G RF Modem (optional)
Power supply
7 - 48 VDC via main power supply, MDB, or RS232
Power consumption (typ.)
Without 4G modem @ 12 VDC: max 500 mA | 75 mA standby | 7.4 mA sleep
With 4G modem @ 12 VDC: max 1.5 A | 100 mA standby | 9.75 mA sleep
Security
2x Secure Access Module (SAM) slots
Environmental
-20°C ~ 70°C (-4°F ~ 158°F) Operating Temperature
-30°C ~ 70°C (-22°F ~ 158°F) Storage Temperature
5% ~ 95% Relative Humidity, Non-Condensing
IP 65 front casing | IP34 reverse side | IK09
Flammability rating
V2 according to UL94, IEC 60695-11-10, -20 and IEC 60950-1
Certifications
Payment: EMV Contactless L1 | Mastercard PayPass L2 | Visa payWave L2 |
American ExpressPay L2 | Discover D-PAS L2 | Interac_Flash L2 | J/Speedy L2 |
Mastercard TQM | qPBOC L1 | qUICS L2 | DK TA 7.2
Security: PCI PTS 6.x, SRED | CSEC | UKCC | DC POS 3.0
Regulatory: FCC | IC | UL | RoHS | CE | UKCA
