Command and control units DIGITECH 400 PULSED
3
4
5
6
7
8
9
10
1
2
1
2
3
Command and control units TA4
Pos. 1 Fast coupling straight polarity
Pos. 2 Fast coupling reverse polarity
Pos. 3 External peripheral attachment (modem, pc ecc.)
Pos. 4 Primary auxiliary circuit fuse
Pos. 5 Supply switch. In the "O" position the welder is off
Pos. 6 Secondary auxiliary circuit fuse
Pos. 7 Fast coupling reverse polarity
Pos. 8 Weld auxiliary control connector
Pos. 9 Power connector for HR26 cooling system
Pos. 10 Supply cable
Pos. 1 Weld auxiliary control connectors
Pos. 2 Centralized torch connection
Pos. 3 Rapid couplings for cooling MIG-MAG welding torch
