CEM MARS 6 Synthesis - Page 54

50
Appendix A: GlassChem 20 Vessels
1 2 3 4
5 6 7 8
9 10 11 12
13 14 15 16
17 18 19 20
21 22 23 24
3. The outside of the cap MUST be positioned below the top of the turntable as illustrated.
4. Place the turntable shield on the turntable and slide the four pins into place through the four pegs.
5. Verify the oor mat positioning, ensuring that the mat is not covering the sensors.
