24
ENGLISH
Use and maintenance manual
Setup
CALIBRATION COMPLETE
▪ Return the gauge to rest position.
▪ The wheel balancer is ready for operation.
In the event of errors or faulty operation, the writing “r.P.”: appears on the display : shift the gauge to the rest
position and repeat the calibration operation exactly as described above. If the error persists, contact the Technical
Service Department. In the event of incorrect input in the rim distance gauge calibration function, press to cancel it.
7.4.2 Diameter gauge calibration E
1. Display the diameter gauge CALIBRATION function from the SETUP menu
2. Place the gauge rod on the spindle shell as shown in the figure and press
3. Turn the gauge downward positioning the gauge rod in contact with the spindle sleeve as shown in the
figure and press
