6. Technical specifications
Input voltage
Motor voltage
Motor power - rated
Motor supply
Max door width
Max door area
Max lifting capacity
Operations in standby
mode
Operator travel speed
Door travel adjustment
Safety obstruction force
system
Light
Autoclose
Infrared safety beams
Radio receiver
Receiver code storage
capacity
180 – 270V AC @ 50/60Hz
24V DC
120W DC
Dual power – 250VA max. mains power supply,with 2 x
1.5Ah 24V battery backup supply
6500mm
12m²
1200N
12 to 30 depending on the door size / weight / height /
duration of power failure
Adjustable – between 90 – 125mm/sec
Manually adjustable limits with 1 to 1 adjustment ratio
Selectable Manual / Adaptive
Bayonet 24V 21W
Dip switch selectable
Optional, but recommended
CENTURION code-hopping 433MHz
22 transmitter buttons
Specifications subject to change without prior notice
Can operate off a solar supply, consult Centurion Systems for assistance
Requires infrared safety beams to be fitted
Page 32
XTrac garage door operator (for sectional and tip-up doors)
