BRIGHTNESS DIMMED 10%
20%
30%
None Sets the display brightness when the unit is left idle for
several seconds.
COLOR
Predefined colors
Custom color
Edit custom color
None Selects the display color for PCM playback
Predefined colors
represents a set of factory defined
colors
Custom color is a user definable color. To Edit the custom
color select the Edit custom color Value. Sub-menus allow
to individually configure Red, Green and Blue components
(RGB) of the custom color.
GAMMA RBG and global
brightness gamma
curve
correction, +/-30%
None Fine adjustment the gamma scale of the RGB
components of the display. Allows to have perfectly
dark background and to match other CH Precision
unit's display color, even at low brightness.
Details of DISPLAY SETTINGS menu Parameters
4.3.1.3 SHORTCUTS
The A1 SETUP >> SHORTCUTS menu allows configuration of the Shortcuts.
Accessible Parameters are:
- SHORTCUT1:
- SHORTCUT2:
- SHORTCUT3:
- SHORTCUT4:
- SHORTCUT5:
- SHORTCUT6:
Defines action for Shortcut #1
Defines action for Shortcut #2
Defines action for Shortcut #3
Defines action for Shortcut #4
Defines action for Shortcut #5
Defines action for Shortcut #6
Note that unused Shortcuts are not displayed. The first available (e.g. non
defined) Shortcut has a Parameter Value of 'None' (the example on the left has
2 defined Shortcuts, hence Shortcut #3 has a Parameter Value of 'None')
The following table details the Parameters of the SHORTCUTS menu:
PARAMETER PARAMETER VALUES REQUIRED OPTIONS REMARKS
SHORTCUT 1 Any Parameter of the AUDIO
SETTINGS and DISPLAY
SETTINGS menus or None
None If SHORTCUT 1 is not defined, Parameter value for
SHORTCUT 1 is set to 'None'. SHORTCUT 2 to 6 are not
displayed in this case.
SHORTCUT 2 Any Parameter of the AUDIO
SETTINGS and DISPLAY
None If SHORTCUT 2 is not defined, Parameter value for
SHORTCUT 2 is set to 'None'. SHORTCUT 3 to 6 are not
34 A1 User Manual Rev 2.0
