CHAFFOTEAUX ARIANEXT COMPACT - Z1 Zone Module Settings

81
Commissioning
ARIANEXT COMPACT
MENU SUB-MENU PARAMETER DESCRIPTION RANGE DEFAUTL
0 NETWORK
0 2 BUS network
0 2 0 Network presence
System interface
Energy Manager
Heat Pump
Room Sensor
Zone Manager
0 3 System interface
0 3 0 Zone number
No zone selected
Zone selected
0 3 1 Room temperature correction 1
0 3 2 SW Version Interface
4 ZONE1 PARAMETERS
4 0 Setpoint
400T Day 19
401T Night 16
402T set Z1 20 (LT) - 40 (HT)
403Zone frost temperature 5
4 1 Free parameters
4 2 Z1 Settings
420Zone 1 temperature range
Low Temp
High Temp
Low Temp
4 2 1 Thermoregulation
Fix Flow T
Basic Thermoreg
Room T Only
Outdoor T Only
Room+Outdoor T
Basic Thermoreg
4 2 2 Slope 1,5
423Offset 0
424Room Infl uence Proportional 20 (LT) - 10 (HT)
425Max T 45 (LT) - 60 (HT)
4 2 6 Min T 20 (LT) - 20 (HT)
4 3 Z1 Diagnostics
430Room T
431Room T setpoint
432Flow temperature
433Return temperature
434Heat Request Z1 OFF - ON
4 3 5 Pump Status OFF - ON
4 4 Z1 Zone Module Settings
4 4 0 Zone pump modulation
Fixed
Modulating on DeltaT
Modulating on Pressure
Modulating on DeltaT
4 4 1 Target deltaT for pump modulation 7 (LT) - 20 (HT)
4 4 2 Pump fi xed speed 100
