CHAFFOTEAUX ARIANEXT COMPACT - Zone2 Parameters; Z2 Settings; Z2 Zone Module Settings

82
Regulation
ARIANEXT COMPACT
MENU SUB-MENU PARAMETER DESCRIPTION RANGE DEFAUTL
5 Zone2 Parameters
5 0 Setpoint
5 0 0 T Day 19
5 0 1 T Night 16
5 0 2 T set Z2
5 0 3 Zone frost temperature 5
5 1 Free parameters
5 1 0 Zone free parameter
5 1 1 Zone free parameter
5 1 2 Zone free parameter
5 2 Z2 Settings
5 2 0 Zone 2 temperature range
Low Temp
High Temp
Low Temp
5 2 1 Thermoregulation
Fix Flow T
Basic Thermoreg
Room T Only
Outdoor T Only
Room+Outdoor T
Basic Thermoreg
5 2 2 Slope 0,6
5 2 3 Offset 0
5 2 4 Room Infl uence Proportional 20 (LT) - 10 (HT)
5 2 5 Max T 45 (LT) - 60 (HT)
5 2 6 Min T 20 (LT) - 20 (HT)
5 3 DIAGNOSTIC ZONE 2
5 3 0 Max Integral Action on Room Control
5 3 1 Z2 Diagnostics
5 3 2 Room T
5 3 3 Room T setpoint
5 3 4 Flow temperature OFF - ON
5 3 5 Pump Status OFF - ON
5 4 Z2 Zone Module Settings
5 4 0 Zone Pump Modulation
Fixed
Modulating on DeltaT
Modulating on Pressure
Modulating on DeltaT
5 4 1 Target deltaT for pump modulation 7 (LT) - 20 (HT)
5 4 2 Pump fi xed speed 100
7 ZONE MODULE
7 1 Manual Mode
7 1 0 ZM Manual mode activation OFF - ON
7 1 1 Z1 Pump control OFF - ON
7 1 2 Z2 Pump control OFF - ON
7 1 4 Z2 Mix Valve Control
OFF
Open
Close
OFF
