Regulation
ARIANEXT COMPACT
MENU SUB-MENU PARAMETER DESCRIPTION RANGE DEFAUTL
17 5 7 Test resistance 2 OFF - ON OFF
17 5 8 Test resistance 3 OFF - ON OFF
17 5 9 Anode output OFF - ON OFF
17 6 Manual Mode - 2
17 6 0 Manual mode activation OFF - ON OFF
17 6 1 Force Hp Heat OFF - ON OFF
17 6 2 Force Hp Cool OFF - ON OFF
17 7 Test & Utilities
17 7 0 Air-purge function
17 7 1 Floor drying cycle
OFF
Functional Heating
Curing Heating
Functional Heating + Curing Heating
Curing Heating + Functional Heating
Manual
OFF
17 7 2 Floor drying total Remaining Days l
17 7 3 Floor drying functional Remaining Days
17 7 4 Floor drying curing Remaining Days
17 8 Energy Manager Statistics
17 8 0 HP Running hours (h/10)
17 8 1 HP On cycles n/10
17 8 2 HP+Res both ON running hours (h/10)
17 8 3 HP Defrost hours (h/10)
17 9 HP Diagnostics - 1
17 9 0 Outside air temperature
17 9 1 HP water fl ow temp
17 9 2 HP water return temp
17 9 3 HP Evaporator temp
17 9 4 HP Suction temp
17 9 5 HP Discharge temp
17 9 6 HP condenser outlet temp
17 9 7 Flow Switch
OPEN
CLOSE
17 9 8 HP Actual Compressor frequency
17 9 9 HP Set Compressor Modulation
17 10 HP Diagnostics - 2
17 10 0 Heat Pump Mode
OFF
Stand by
Cooling
Heating
Freeze Protection
Defrost
High Temperature Protection
Timeguard
System Fail
17 10 1 HP Error
