4
To avoid possible SERIOUS INJURY to finger
from moving garage door opener:
• ALWAYS keep hand clear of sprocket while
operating opener.
• Securelyattach sprocketcover BEFORE
operating.
To avoid SERIOUS damage to garage door
opener, use ONLY those bolts/fasteners
mounted in the top of the opener.
Mounted in the
garage door opener
HARDWARE
H1 (3)
Hex Screw
#8x3/8"
(Packed with the
sprocket cover)
H1 (2)
Washered Bolt
5/16"-18 x 1/2"
.
NOTE: ONLY use the bolts removed from the
garage door opener. Place the garage door
opener on the packing material to prevent
scratching.
1.1 Remove the two bolts from the top of the
garage door opener.
1.2 Align the rail and the styrofoam over the
sprocket.Cut the tape from the rail,belt,
and styrofoam.
1.3 Fasten the rail with the previously removed
bolts(H1).
1.4 Position the chain around the garage door
opener sprocket.
1.5 Install the sprocket cover by squeezing the
sidesand inserting the tabs into the slots
on the garage door opener.
Assembly
1 Attach the rail to the garage door opener
