Chamberlain CSW200UL - Concrete Pad and Arm Attachment; Sample of Standard Arm Attachment

10
CONCRETE PAD AND ARM ATTACHMENT





6"
Above
Ground
28"


Bracket Height






24"
Sample of Standard Arm Attachment (See next page for layout)
28"
46"
25"
35.5"
29.5"
24"
11"
10"
27.5"
Long Arm is
on Top of
Bracket!
Bottom of CSW
2"









Top View of Chassis
Approximate placement of high
voltage and/or low voltage
conduits.



