SETTING THE TIMER
“ON”
1.
2.
3.
Master Board Second Board
Master Board
Second Board
1.
Single Operator
Master/Second Operators
with Timers ON
with Timers OFF
M/S LINK
Master/Second control boards are interchangeable.
M/S LINK
NOTE: If a secondary photoelectric sensor
device is NOT used when the timer is ON, the
gate WILL hit a vehicle obstructing the gate
path before reversing during the close cycle.
“OFF”
NOTE: Push button once to open gate, push
button again to close gate.
2.
