ADJUSTING REVERSING SENSOR(S)
The level of reverse sensitivity depends on the weight of the gate
and the condition of installation.
Sensor is too sensitive
Sensor is not sensitive enough
Reverse SensorAlarm Sensor does not need to be adjusted except where noted below.
Maximum
Sensitivity
Maximum
Sensitivity
Minimum
Sensitivity
Minimum
Sensitivity
DC2000™ Reverse Sensor

Charge OK
ON 
