Attach Operator to Gate
IDENTIFY HINGE TYPE
The illustrations below show common gate hinges. There are many styles of hinges available.
Gate Post
Gate Post
Gate Post
J-Bolt Hinge Point
J-Bolt Hinge Point
Butt Hinge Point
Barrel Hinge Point
J-BOLT HINGE
BARREL HINGE
BUTT HINGE
TOP VIEW
Butt Hinge Point
Gate Post
Gate Post
