6
Specifications
INTRODUCTION
Carton Inventory
Main AC Supply: 110-127Vac / 220-240Vac; 50/60Hz
Motor Voltage: 24 Vdc
Input Power: 100 W
Ambient Temperature Range: -25 ~ +50 ˚C
Maximum Weight for single Gate Leaf: 350 Kg
Maximum Width for single Gate Leaf: 1.8 m, 2.5 m (with electric lock)
Maximum Open Angle: 120˚
Protection Level: IP 44
Maximum Travel Distance: 350 mm
Daily Cycle Rate: Maximum 50 cycles per day
Weight per Gate Operator: 6 Kg
Installation
Manual
(Not shown)
Remote Control (2)Post Mounting
Bracket (2)
Gate Mounting
Bracket (2)
Washer and Bolt
(attached to the arm)
Control Box
Release Key (3) Hairpin Clip (2)Clevis Pin (2) M8x60 Screws (8)
Operator
Model LA350 (2)
