7
Track
Bolt
3/8" - 16 x 3/4"
Operator
Header End
Operator
End
Bolt
3/8" - 16 x 3/4"
Bolt
3/8" - 16 x 3/4"
Flange Hex Nut
Flange Hex
Nut
Flange Hex
Nut
Bolt
3/8" - 16 x 3/4"
Slide trolley onto the track.
Attach track to operator.
Track
Trolley
Operator End
ASSEMBLY
4
5
