Your garage door opener is packaged in one carton which
contains the motor unit and all parts illustrated below.
Accessories will depend on the model purchased. If
anything is missing, carefully check the packing material.
Hardware for assembly and installation is shown on the
next page. Save the carton and packing material until
installation and adjustment is complete.
Carton Inventory
Multi-Function
Door Control Panel
Motor Unit with a Light Lens
(varies depending upon
model purchased)
Trolley
Idler Pulley
Chain Spreader
SECURITY✚
®
Single-Button Remote Control
SECURITY✚
®
3-Button Remote Control
Model PD210CD (1)
Model PD210CDV (1)
Model PD212CD (2)
Model LC250 (1)
Model HD200CD (1)
Model PD612CD (2)
Model LC500 (2)
Door Bracket
Header Bracket
Straight Door
Arm Section
Hanging Brackets
Safety Labels
and
Literature
Curved Door
Arm Section
Safety Reversing
Sensor Bracket (2)
“U” Bracket
The Protector System
®
(2) Safety Reversing Sensors
(1 Sending Eye and 1 Receiving Eye)
with 2-Conductor White & White/Black
Bell Wire attached
Chain and Cable in
Dispensing Carton
2-Conductor Bell Wire
White & White/Red
Rail
Front (header)
Section
Rail
Center/Back
Sections
Door Control Button
Model LC250
Model PD210CDV
Model HD200CD
