Champion D10 - Unit Standard Operating Parameters

D10.D15.DRS15-MANS
Apr ‘19
- 22
-
‘CSC300’ Controller (cont’d)
Unit Standard Operating Parameters
The chart below indicates the standard operating parameters programmed into the ‘CSC300’ Controller at the
factory.
Model
C
ontrol
Mode
Load
Pressure
Offload
Pressure
High
Pressure
Alarm
High
Pressure
Shutdown
Idle
Shutdown
(minutes)
Routine
Service
H
ours
Grease
Service
Hours
D10
Load/
Offload
125 psi
(8.6bar)
145 psi
(10bar)
150 psi
(10.3bar)
155 psi
(10.7bar)
5 2000 9500
D15
Load/
Offload
125 psi
(8.6bar)
145 psi
(10bar)
150 psi
(10.3bar)
155 psi
(10.7bar)
5 2000 3600
DRS 15
Variable
Speed
135 psi
(9.3bar)
145 psi
(10bar)
150 psi
(10.3bar)
155 psi
(10.7bar)
2 2000 3600
A description of the terminology used in the above chart is as follows:
HP: Horsepower of the Unit.
Load Pressure: The pressure at which the Unit will begin to compress air.
Offload Pressure: The pressure at which the Unit will stop compressing air.
High Pressure Alarm: The pressure (above the Offload Pressure) at which an alarm will be noted.
High Pressure Shutdown: The pressure (above the Offload Pressure) at which an alarm will be noted and the
Unit will shut off.
Idle Shutdown: The amount of time the Unit will idle (run but not compress air) after it has reached the Unload
Pressure before shutting off.
Routine Service Hours: The maximum allowable time between regular maintenance/service of the Unit.
Grease Service Hours: The maximum allowable time between motor lubrications.
The above chart is supplied for information only. Serious consequences could result should any of the
parameters be adjusted by someone who is not familiar with the correct and safe operation of the Unit.
Any adjustments made to the above parameters by others (other than a qualified Technician) resulting in the
incorrect operation of the Unit, damage to the Unit, or damage to property is not covered by the Champion
Warranty.
Please consult with your Champion Distributor or contact Champion directly should you have any questions or
concerns about any of the information in the chart above, or in this manual.
