Chattanooga Intelect Mobile Ultrasound - Sound Head Specific Technical Data

20
Intelect
®
Mobile Ultrasound
ULTRASOUND TECHNICAL SPECIFICATIONS CONTINUED
1 cm
2
Sound Head
Frequency ................................................................... 3.3 MHz (all +/- 5%)
Power .................................................................................. 0 watt to 2 watts
Effective Radiating Area ................................................. 0.7 cm
2
– 1 cm
2
Maximum beam non-uniformity ratio ............................................ 5.0:1
Beam Type ...................................................................................Collimating
Degree of Protection Against Ingress of Water ........................... IPX7
*Coupling .........................................................................................1-2 watts
5 cm
2
Sound Head
Frequency .......................................................................1 MHz (all +/- 5%)
Power ............................................................................... 0 watt to 10 watts
Effective Radiating Area ................................................. 3.5 cm
2
– 5 cm
2
Maximum beam non-uniformity ratio ............................................ 5.0:1
Beam Type ...................................................................................Collimating
Degree of Protection Against Ingress of Water ........................... IPX7
*Coupling .........................................................................................2-8 watts
10 cm
2
Sound Head
Frequency .......................................................................1 MHz (all +/- 5%)
Power ................................................................. 1 MHz: 0 watt to 20 watts
..............................................................................3 MHz: 0 watt to 10 watts
Effective Radiating Area ............................................... 6.8 cm
2
– 10 cm
2
Maximum beam non-uniformity ratio ............................................ 5.0:1
Beam Type ...................................................................................Collimating
Degree of Protection Against Ingress of Water ........................... IPX7
*Coupling ........................................................................1 MHz: 2-18 watts
............................................................................................... 3 MHz: 2-8 watts
2 cm
2
Sound Head
Frequency .......................................................................1 MHz (all +/- 5%)
Power .................................................................................. 0 watt to 4 watts
Effective Radiating Area ................................................. 1.4 cm
2
– 2 cm
2
Maximum beam non-uniformity ratio ............................................ 5.0:1
Beam Type ...................................................................................Collimating
Degree of Protection Against Ingress of Water ........................... IPX7
*Coupling .........................................................................................1-4 watts
*Output range at which Coupling Control, when enabled, is operational. Outside this range, the unit will always indicate coupled.
SPECIFICATIONS
