Chenbro SR301 Plus series User Manual

SR301 Plus Series
│ 6
1. Product Overview
The SR301 chassis has been modified to support both tool-less 3.5” HDD carrier and PCIe 3.0 slot, and transformed into feature-
advanced SR301 Plus. Beneath the chassis, an information sticker reads revision and manufacturing codes which are necessary for
technical support. This chapter provides a high-level overview of the system features and available options. More details for each
major sub-system, feature or options are provided in the following chapters.
Table 1 Chenbro SR301 Plus specifications
Feature
Description
MB Form Factor
 Mini-ITX (6.7" x 6.7")
Dimension
(D x W x H)
 310.0 x 200.0 x 270.0 (mm)
12.20" x 7.87" x 10.63" (w/o bezel)
Drive Bay
 4 x 3.5" Hot-swap, 2 x 2.5" Internal
Storage Backplane
 1 x 3.5" 4-port 12Gbps Mini-SAS HD Passive Backplane
 1 x 3.5" 4-port 12Gbps SAS/SATA Passive Backplane
PSU Form Factor
 PS/2 Single (with 120 mm Fan)
Indicator
 1 x Power Status, 1 x HDD Status, 1 x System Alarm
Front Control
 1 x Power On/Off, 1 x System Reset, 2 x USB2.0/USB3.0 (Option)
Cooling Fan
 Front: 120 x 25 mm (1)
System Security
 Intrusion Switch, Key Lock, Padlock Loop, Kensington Slot
Expansion Slot Opening
 1 x Low Profile
Net Weight
 5.2 kg/11.45 lb
Gross Weight
 7.0 kg/15.42 lb
Cubic Feet
 1.85
Container Loading
 20ʼ: 564, 40ʼ: 1134, 40'H: 1284 (Single Packing)
Slide Rail
 Supported
