CAC Gasoline Engine Maintenance And Servicing Manual
13
Application parameters：
Lubricant(With temperature at - 10℃ or more) SAE10W/30—50( grade SF)
Gasoline 93#(SH0041) Common unleaded
Gasoline
Engine oil pressure Idling 100kPa min
2000r/min(80℃) 280kPa min
Engine oil capacity (L) 3.86(New oil filter)
Oil pump pressure regulator starts to open(pressure) kPa 440±20
Engine oil filter by-pass valve starts to open (pressure) kPa 78—118
Coolant 50%Glycol+50%Soft water(Rate
by volume)
Coolant capacity (Total)(L) 8
Thermo-sister Starts to open (Temperature) ℃ 85—89
Fully open(temperature)℃ 99—102
Expansion tank pressure cap pressure kPa 160
Fan diameter (mm) 280
Fan speed r/min Ⅰspeed 1500
Ⅱspeed 2800
Air filter 1GD129607G
