Chery A11 2003 - Fault Diagnostic Flow Chart

Beginning
Ignition off, connect scan tool.
Turn ignition to ON position
Enter 03 (electronic brake) at ADDRESS
NO
Is there communication?
YES
go to FAULT W/O CODEDIAGNOSTIC
CHART
go to FAULT CHECK CHART,
WITHOUT CODES
Enter 02
(
error in
q
uir
y)
at ADDRESS
Intermittent fault (display with /SP)
Continuous Fault
Clearing fault code
Recording fault code
Go to INTERMITTENT FAULT
DIAGNOSTIC PROCEDURE,
repair problem.
Go to FAULT W/CODE DIAGNOSTIC CHART,
re
p
air
p
roblem.
Clearing fault code
Turn ignition off, disconnect scan tool.
N
ot Normal
Vehicle Drive Test
N
ormal
END
1. Faut Diagnostic Flow Chart
