【8】、Valve mechanism and cylinder head removal, check and installation
1.Valve mechanism for 478 and 480 engine：
Rocker arm
-
8
Valve locking piece-16
Rocker arm seat-8
Fit clearance with hole
0.023/0.065
Rocker arm stud-8
Tightening torque 18-23Nm
Upper Valve spring seat
-
8
Valve spring -8
Valve oil seal spring seat assy-8
Assembly before valve oil seal
spring and valve installation
Rocker arm seat washer
-
8
hydraulic lifting rod-8
Rock arm nut-8 .ti
ghtening torque
25-29n.m
Exhaust valve-
4. fit clearance between left valve
stem and valve guide is 0.046-0.095
Intake
valve
-
4. fit clearance between valve
stem and valve guide is 0.02-0.069
Fig.19
