CAC Gasoline Engine Maintenance And Servicing Manual
55
3) The removal and installation of thermostat seat with thermostat assembly
——Loosen three M6×40 bolts and remove them
——Remove thermostat seat with thermostat assembly
——Pry out spring clip by chisel or screwdriver
——Take out the thermostat
——Take out sealing gasket
——Remove sealing gasket of thermostat seat
Measure the opening temperature of thermostat in hot water.
Fig. 97
Fig. 98
Fig. 99
