CHERY AUTOMOBILE CO., LTD Automatic Transmission Fault Diagnosis Manual
43
Gear
djustment procedure:
The adjustment of gearshift
cable is important to the
compliance of the position of the
shift lever with that of the gear
the shift lever to
heck if the
in position P.
2. strument panel,
3.
. Loosen the gear switch and tighten the
bolt;
. Pull the gear shifter arm to the limit,
i.e. position P;
hift cable and
Fix the gearshift cable with the
adjusting bolt and nut;
Install the gearshift box, gear position
display board;
Install the battery.
shift cable adjustment
A
shifter arm. Pull
position P and then c
gear shifter arm is
If not, adjust the gearshift cable
in accordance with the following
procedure:
1. Remove the battery,
Remove the in
shift box cover and shift box;
Pull the shift level to position P;
4
5
6.Tighten after the gears
shift level is connected;
7.
8.
9.
