CHERY AUTOMOBILE CO., LTD Automatic Transmission Fault Diagnosis Manual
S
tomatic transmission
rake band C’
ssembly procedure:
Remove the transmission
assembly from the whole
vehicle;
Remove brake C’ from the
transmission;
Remove the snap ring on the
Take out cylinder head and piston
C’.
Remove the snap ring on the
piston.
ervice of major parts on the
au
B
A
1.
2.
3.
hydraulic cylinder head of
brake C’.
4.
5.
80
