CHERY AUTOMOBILE CO., LTD Automatic Transmission Fault Diagnosis Manual
Install bottom v9. alve plate’s
outer side compression plate
and fix it with bolts;
Tightening torque: 8Nm
. Assemble the control valve
plate assembly;
. Install the valve plate assembly
on the automatic transmission;
. Install the assembled
transmission on the vehicle.
isassembly procedure:
ote: Take care that the spring will
mp out when removing the ma
lve plate’s compression plate.
Remove the automatic
transmission assembly from the
vehicle;
Remove the bottom valve plate
from the transmission;
Remove the main valve plate;
Loosen the bolt on the shuttle
valve’s compression plate and
e
5. Take out 3
rd
–4
th
shift valve;
10
11
12
Main valve plate
D
N
ju in
va
1.
2.
3.
4.
take off the compression plat
carefully;
141
