CHERY AUTOMOBILE CO., LTD Automatic Transmission Fault Diagnosis Manual
66. Turn over the transmis
167
sion by 90 degree, as shown by the figure;
8. Install the valve plate’s fixing
bolt. The bolt’s tightening
Install the oil pan and oil pan
70. Install the torque converter to
ensure that the converter is
installed to its correct
71.
67. Install the control valve plate assembly to ensure that the manual valve is installed to the
correct position.
6
torque is 8Nm.
69.
gasket.
position.
Install the transmission
assembly on the vehicle.
