Maintenance Manual for Chery·Windcloud．．．．．．．．．．．．．．．．．．．．．．．．．．Sunroof
4.3 Replacing glass plate
4.3.1 Fully open sunroof.
4.3.2 Detach the glass plate lock pin from fixed driving
base with a screwdriver as shown in the figure,
then take out lock pin (the same with the other
side).
4.3.3 Turn the glass plate fixing pin clockwise to a 90º
position with a minus screwdriver and take it off
(the same with the other side).
4.3.4 Carefully pull the glass plate out of mechanism
group with both sides being parallel.
Page 16 of 37
