SQR7080 Service Manual 372 Engine Mechanical System
27
Chery Automobile Co., Ltd
2 Remove the oil pan from the cylinder body.
Attention Do not make the oil pan flange section to be
deformed.
3 Remove the oil collecting filter and its flange
Attention The filter flange is not reusable.
4 Dismount the oil pump assembly and oil pump
cushion
5 Dismounting of oil seal stand
