SQR7080 Service Manual 372 Engine Mechanical System
Chery Automobile Co., Ltd
8
3.5 Even if the damages on the outer appearance can not be confirmed, the belt should be replaced
under any of the following circumstances:
3.5.1If the water in the water pump is leaked, which makes it necessary to refill the water
continuously;
3.5.2 There are much oil stains on the belt, the belt should be replaced for the rubber will be damaged
when it is expanded;
3.6 Specifications and model of the timing belt
Part number 372-1007081
Belt wide ２５.3mm
3.7 Timing belt tensioner
Turn the belt tensioner supporting stand bolts to see if there are any abnormal sound. Check to see if
there are any damages on the contacting surface of the belt.
Specifications and model of the timing belt tensioner
Part number
372-1007030
Wide
２７．０mm
Outside diameter
φ50mm
3.8 Check to see if there are any damages on the outer appearance
Specifications and model of clockwise pulley
ＥＦ Model
Item
ＧＬ、ＺＬ、ＧＳ、ＺＳ
Diameter of camshaft timing
gear （mm）
φ110.7
+0.1
-0.2
Diameter of crankshaft timing
gear （mm）
φ54.65
+0.7
-0.13
3.9 Baffle of crankshaft timing gear
Check to see if there is any deformation
Standard size of crankshaft timing gear：
Wide 28.6mm
